46 inch video wall full hd full color 500nits 3x3 lcd display
narrow bezel 10mm
1, Main Features :
♦ Excellent ultra narrow bezel design with just 10 mm bezel width
between screens.
♦ Built-in 3D noise reduction, making the image clean and outline
more vivid.
♦ Full HD display 3840x2160 display.
♦ LED backlit technology brings you perfect visual effect.
♦ 4K input supported.
2, Application :
♦ Transportation Industry
LCD video wall could be used in the information display terminal of
transportation industry, such as airports, ports, metro, highway.
Because more information could be displayed integrated and timely
in the LCD display.
♦ Financial Industry
LCD video wall could be used in the information display terminal of
financial industry, such as stock and security market. These places
are usually very spacial and there is crowded population. The wide
viewing angle of LCD video wall makes people see the displaying
information clearly and effortlessly from different directions and
positions.
♦ Commercial Industry
LCD video wall could be used in the display terminal of commercial
industry, such as advertising, media, product presentations etc.
The LCD video wall could meet the high requirement for bright
images and vivid videos because of its high definition and high
brightness. At the same time, the LCD video wall could work around
the clock for years without break, which makes it the best choice
for commercial industry to display information with intermission.
♦ Management and Control System
LCD video wall could be used in the display terminal of management
and control system such as fire-fighting, meteorology, maritime,
food prevention, transportation hub etc. The management and control
system features that a wide monitoring range must be displayed to
the control center so that the manager could make a quick response.
In this case, the independent displays of each screen in LCD video
wall makes a great difference for the manager in the management and
control center.
♦ Safety Monitoring System of Mining and Energy Industry
High definition, wider monitoring range and multi-screen displays
of LCD video wall increase the levels of the safety in production.
Even the the dark mine images could be displayed clearly in the LCD
video wall.
♦ Education and Conference System
The LCD video wall could display the information prepared by the
educator or conference organizer in advance, which could help the
listeners understand the information better, and at the same time,
which could save the participants’ a lot of time. In a word, the
LCD video wall could improve the efficiency greatly of education
and conference.
3, Product Specification :
| Panel Specification |
| Model No | VD-D3D460G |
| Panel Size | 10MM |
| Aspect Ratio | 16 : 9 |
| Active Display Area | 1018.3(W) x 572.5(H) |
| Backlight | LED |
| Max Resolution Support | 3840x2160(Max) |
| Color | 16.7M |
| Brightness(nits) | 500nits |
| Contrast | 3500 : 1 |
| Visual Angle (H/V) | 178°/178° |
| Response Time | <6ms |
| Life(hrs) | >50,000(hrs) |
| Video Wall Controller(Built-in each screen) |
| VGA input | 1 |
| DVI input | 1 |
| HDMI Input | 1 |
| Composite Video input | 2(BNC x 2) |
| Y,Pb,Pr/Y,Cb,Cr input | 1(BNC X 3) |
| Composite Video Output | 2(BNC X 2) |
| S-video | 2(BNC X 2) |
| Control signal input and loop out | RS232(RJ45-8) |
| Split Screen (Matrix is optional) | Support Picture in Picture(PIP/POP) |
| Video System |
| Color System | PAL/NTSC/SECAM |
| HDTV Mode | 480P, 576P, 720P, 1080P |
| OSD Display(Menu Language) | Chinese/English |
| Power |
| Power supply | AC 100V ~ 240V, 50/60Hz |
| Maximum Power Consumption | <170W |
| Standby Power Consumption | <3W |
| Temperature |
| Working Temperature | 0° ~ 50° |
| Storage Temperature | 20° ~ 60° |
| Working Humidity | 20%~80% |
| Storage Humidity | 20%~80% |
| Installation System |
| Installation | With wall bracket for each single unit lcd |
| Gross Weight | 25kg |
| Dimension | 1030X585.5X70 mm |
| Accessories |
| Split LCD Unit | Yes |
| Bracket | Yes(wall bracket for each single unit lcd) |
| Power cable | Yes |
| Remote controller | Yes |
| Video wall controller | Yes(Built-in each screen) |
| Splicing software | Yes |
