DID lcd video wall panel 40 inch seamless tv wall for advertising
1, Product Description.
A video wall is a special multi-monitor setup that consists of
multiple computer monitors, video projectors, or television sets
tiled together contiguously or overlapped in order to form one
large screen. Typical display technologies include LCD panels,
Direct View LED arrays, blended projection screens, Laser Phosphor
Displays, and rear projection cubes.
Screens specifically designed for use in video walls usually have
narrow bezels in order to minimize mullion, the gap between active
display areas, and are built with long-term serviceability in mind.
Such screens often contain the hardware necessary to stack similar
screens together, along with connections to daisy chain power,
video, and command signals between screens. A command signal may,
for example, power all screens in the video wall on or off, or
calibrate the brightness of a single screen after bulb replacement.
2, Product Features.
- Full hardware architecture, no CPU or operating system;
- Multi-bus parallel processing, powerful processing function;
- Start time less than 5 seconds;
- No risk of virus infection, ensuring excellent security;
- Integrate multi-channel video signal types: HDMI, DVI, VGA, CVBS
(composite video);
- Composite video can be looped out;
- Embedded 3D video bright separation circuit unit;
- Embedded 3D progressive processing and frame-rate normalization and
conversion circuit unit;
- Embedded 3D digital signal noise reduction unit;
- Unit supports driving 1920x1080 LCD screen;
- RS232 remote control, each unit can be looped out;
- Continuous operating24 hours a day;
- Easy to operate, flexibly operate the system with the Foretell
large screen control software;
- Open underlying communication protocol, users can flexibly use
third-party control system or prepare software to construct large
screen engineering system.
3, Product Specification :
| Panel Specification |
| Model No | VD-D2D400A |
| Panel Size | 20MM |
| Aspect Ratio | 16 : 9 |
| Active Display Area | 885.6(W) x 498.15(H) |
| Backlight | LED |
| Max Resolution Support | 1920x1080(Max) |
| Color | 16.7M |
| Brightness(nits) | 700nits |
| Contrast | 3000 : 1 |
| Visual Angle (H/V) | 178°/178° |
| Response Time | <6ms |
| Life(hrs) | >60,000(hrs) |
| Video Wall Controller(Built-in each screen) |
| VGA input | 1 |
| DVI input | 1 |
| HDMI Input | 1 |
| YUV/YPbPR | 1(BNC x 3) |
| S-(YC) | 1(BNC X 3) |
| Composite Video Input/(AV) | 3(BNC X 3) |
| Composite Video Output | 2(BNC X 2) |
| Control signal input and loop out | RS232(RJ45-8) |
| Split Screen (Matrix is optional) | Support Picture in Picture(PIP/POP) |
| Video System |
| Color System | PAL/NTSC/SECAM |
| HDTV Mode | 480P, 576P, 720P, 1080P |
| OSD Display(Menu Language) | Chinese/English |
| Power |
| Power supply | AC 100V ~ 240V, 50/60Hz |
| Maximum Power Consumption | <250W |
| Standby Power Consumption | <3W |
| Temperature |
| Working Temperature | 0° ~ 50° |
| Storage Temperature | 20° ~ 60° |
| Working Humidity | 20%~80% |
| Storage Humidity | 20%~80% |
| Installation System |
| Installation | With wall bracket for each single unit lcd |
| Gross Weight | 25kg |
| Dimension | 911.7X524.2X128 mm |
| Accessories |
| Split LCD Unit | Yes |
| Bracket | Yes(wall bracket for each single unit lcd) |
| Power cable | Yes |
| Remote controller | Yes |
| Video wall controller | Yes(Built-in each screen) |
| Splicing software | Yes |
