Silver Aluminum Frame Touch Screen Interactive Whiteboard ,
Interactive Touch Screen Smart Board
1, Products Features :
1), support multi language
2), different sizes and frames for choice
3), based on infrared touch technology
4), modular design patent and hand gesture recognition patent
5), any solid opaque objects can be used for writing or drawing,
like finger, stylus pen or pointer.
6), multi touch, 4 point touch to 10 point touch, no need driver,
plug and play.
7), with powerful whiteboard software drawview 4.3.6
8), widely used in classroom, meeting room, conference room, etc.
9), with rich experience on making interactive whitebaords for many
world-class suppliers, OEM/ODM is welcome.
2, Our interactive smart board hardware Features :
| 1), Board writing smoothly and fluently ,with high precision ; |
| 2), No light spots, to protect user’s eyes ; |
| 3), could be used also as a traditional white board using water pen
for writing. |
| 4), All kinds of board material can satisfy different requirement
of customers. |
| 5), The main PCB is separated from the board, be convenient for
after-sale to repair quickly |
| 6), Users can expand the application functionality themselves |
| 7), The reverse side use zinc coating plate, to avoid whiteboard
working abnormally because of electromagnetic interference. |
| 8), Scratches on the board surface will not affect the use of
interactive smart board |
| 9), One key for positioning calibration. |
| 10), The main PCB is separated from the board, be convenient for
after-sale to repair quickly. |
3, Products Summary :
Interactive whiteboard connects with a general computer by a USB
cable, the display output of computer can be projected on the
whiteboard through a projector. After calibration, touch and
tracking information from the board will be transferred into
pointer click and movement of the mouse, and by Gaoke software or
other program, all click, tracking and writing information will be
displayed on the board at real time.
4, Product Specification
| Screen Panel | size | 42 inch |
| Viewing Area | 919.3 X 517.1mm |
| Resolution | 1920 X 1080(pixels) |
| Brightness | 350 cd/m2 nits(typ.) |
| Contrast | 5000 :1 (typ.) |
| Pixel | 0.0798mm X 0.2394mm |
| Visual Angle | 178°(H)/178°(V) |
| Color | 1.07G |
| Response Time | 6.5ms |
| Life | 50,000hrs(mini.) |
| TV | TV Mainoard | PAL, NTSC/SECAM(Optional) |
| Input | RFX1, TV-USBX2, CVBS X2(AVX1), HDMIX3(built-inx1), VGAX1, PCAUDIOX1,YPBPRX1, RFX1, RS232X1, S-videoX1, Touch-usbX1 |
| Output | AVOUTX1, EARPHONEX1 |
| I/O Optional | Input : TV-USBX1, VGAX2, PCAUDIOX2 ; Output : VGAX1 |
| Android Solution | System Version | Android 4.4.2 OS ; English language |
| Mainboard | ARM Cortex A7, 1.4Ghz, Quad core ; |
| Memory | RAM : 2GB DDR3, ROM 8GB |
| I/o ports | Input Port(option) | HDMI *3,VGA*1,PC-Audio*1,YPbPr *1,AV*1,TV*1,
TV-MIC*1, RS232*1, UHD*2 |
| Output Port | HDMI *1, AV*1, Earphone *1, coaxial *1, TV-AUDIO*1,
RS232*1 |
| Touch System | Other Port(option) | LAN*1, Media-USB2*1, PC-USB*1,Touch-USB*2,Media-USB*1,
PC-USB*2 |
| Technology | Infrared multi touch,real 6 points to 10 points,support touch
by any opaque object(Such as finger or whiteboard pen) |
| Glass | 4mm tempered glass, transparency rate >88%, resolution :
32768 X 32768, against light interface. |
| Technical Parameter | response time : 15ms,accuracy<2mm; power by USB port,
Voltage : DC 5v±6%, Power : 0.9W |
| Compatible System | Multi point touch : Window 7/8,Window 7 professional,
Window 7 Home Premium, Android(need add patch to
system code) ; Single point Touch : Window 7/ Windows XP/
Vista/Linux/Mac/Android/Wince |
Built-in PC
(option) | CPU | Intel Core I7 / i5/ i3 ; Integrated HD Graphics; Built-in HD
audio 6(Realtek ALC661) |
| Memory | DDR3 1333Mhz 4G/8G option |
| HDD | SATA 500GB/1TB option |
| WIFI | Optional, WIFI with Antenna, 802.11 b/g/n |
| PC ports | HDMI x 1, VGA x 1, USB x4, RJ45 x1,Pcaudio X1, Rs232 X1,
DC 19V X1 |
| Power Consume | Max | <100W |
| Standby | ≤0.5W |
| Environment | Working | Temperature : 0℃ ~ 40℃,
Humidity: 20%~80% non-condensing |
| Storage | Humidity: 10%~90% non-condensing |
| Outlooking | Material&Color | Front case-metal ; backside : Plastic, Color : Black |
| Vesa Mount | 600mm x 400mm(4-M8) |
| Dimension | Product Dimension | 1029 x 621.5 x 119.6mm |
Package Dimension | 1135 x 725 x 190mm |
| CBM | 0.158 |
| Net Weight | 29kg |
| Gross Weight | 36kg |
| Accessory | Remote Control *1, Power Cable *1, Touch Pen*2,User
Guide*1,Warranty Card *1 |
We will default I3 processor as standard configuration of internal
PC for touchscreen PC if you have no special configuration
requirements in your inquiry,
